Model

SF-600FM-MX

Camera

Image Device

1/2.9" Sony Low Illumination CMOS

Horizontal Resolution

2.0M/1080P

Effective Pixels

1920(H)×1080(V)

Mini. Illumination

Color: 0.1Lux\  B/W: 0.01Lux / IR ON:0 Lux

S/N

≥50db

Optical Zoom

10X optical zoom f=5.1mm(W) ~ 51mm(T)  ±5%

IRIS

F1.6 - F2.8

View of Angle

H：51.8°（W）～5.86°（T）   V：39.1°（W）～4.4°（T）

White Balance

Auto/manual/indoor/outdoor

BLC

Support

Electronic Shutter

1/2 - 1/20,000s

WDR

D_WDR

Noise Reduction

2D_DNR

Day & Night mode

IR-CUT

Max. IR LEDs Length

Ø16*2 , up to 50 meters , Smart IR

Heater & Blower

Auto temperature control

Video Output

HYBRID AHD/TVI/CVI/CVBS

PTZ

Horizontal

360°endless rotate , Speed  0.1°-50°/s

Tilt Rotation Range

94°

Auto Flip

Horizontal 180°, Vertical 90°

A-B Scan

User programmable

A-B Scan Speed

1-9 levels setting available

Dwell Preset

1-60s interval available

Preset Points

128

Go to Preset Speed

50°/s

Guard Tours

3 groups

Guard Points

Max.16 points, dwell time user selectable 02～60S

Park Action

Home/360° scan/A-B scan/Tour 1-3

Park Time

01-60mins available

PWR on Action

Memory/No Action/A-B scan/360° scan/Home/Tour 1-3

Ambient light detection

Support

IR Illumination On

1-15 grades selectable

Communication Protocol

Pelco-D, Pelco-P

Baud Rate

1200/2400/4800/9600bps

General

Operating temperature

Indoor: 0°~ +40°   Outdoor: -40°~ +60°

Operation menu

English

Humidity

≤95% Non Condensing

Power

DC12V /3A

Consumption

20W (MAX)

Protection Grade

Transient voltage 3000V
