Model

SF-FHD322APZ-2-ICR-G1

Camera

Image Device

1/2.7" 2.0MP Progressive Scan CMOS

Horizontal Resolution

2.0M/1080P

Effective Pixels

1920(H)×1080(V)

Electronic Shutter

1/25s~1/50,000s

Image System

PAL/ NTSC

Synchronization

Internal

Mini. Illumination

0.05Lux(F1.2,AGC ON),0 Lux with IR ON

Max. IR LEDs Length

2pcs Array Leds , 20M , Smart IR

Day/Night

IR Cut Filter Auto Switch

Lens Type

Fixed 3.6 MM (2.8MM Optional)

Video Output

1CH HD_AHD/TVI/CVI/960H output

OSD

OSD Menu

UTC , External OSD Joystick (Optional )

Noise Reduction

2D_DNR

BLC

Auto

WDR

/

General

Transmission Distance

Over 500m via 75-3 coaxial cable

Waterproof

IP66

Working Temperature

-10℃~50℃

Working Humidity

10%~90%

Power Consumption

300 mA

Power Supply

DC12V±10%
