1920*1080 low illumination CMOS
Low latency, support H.264, H.265 encoding
Support ONVIF, CG
Support audio in
metal case, support IP69K waterproof
Support multiple lenses, support wide angle.
Support multiple data protection, suitable for various vehicle environments.
Infrared distance 10-15 meters
Working temperature: -30°C-70°C
|
|
Model |
SF-FN327K-G3-ICR |
|
camera |
Cmos |
1/2.9‘ BSI progressive scan CMOS |
|
Minimum illumination |
0.1Lux @(F1.2,AGC ON),0Lux（IRLED ON） |
|
|
shutter |
auto /manual, 1/25~1/10000 |
|
|
Lens |
Support wide-angle lens |
|
|
Web Browser |
Edge, Chrome, Firefox, mobile |
|
|
video |
encoding |
H.264/H.265/MJEPG(Optional) |
|
Coding rate |
32Kbps~8Mbps |
|
|
Max stream |
main: max1920*1080，30fps |
|
|
Image |
WDR |
DWDR，85db |
|
SNR |
≥50db |
|
|
Day/night |
Auto B/G Color |
|
|
Noise Reduction |
auto/manual |
|
|
Exposure mode |
auto/manual |
|
|
Image rotation |
90°、180° |
|
|
Audio |
Audio in |
Mic in |
|
Audio encoding |
G.711U |
|
|
Net |
Network protocol |
TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP, |
|
Connection Protocol |
ONVIF/CGI |
|
|
Connectors |
Connectors |
6 Pin aircraft connector |
|
IR LED |
Hidden IRLED |
|
|
Other |
IR distance |
10-15m |
|
Operating temperature |
-30℃~70℃ |
|
|
Working humidity |
10%~90% |
|
|
Power |
DC12V±10% |
