1/2.9" 2 megapixel low light cmosCMOS
Support 1920*1080 HD resolution
Support multi-stream transmission
On-board design, good anti-shock and weather resistance.
Suitable for commercial vehicle side view camera, waterproof up to IP69k
Support ONVIF v16.12standard protocol
High temperature resistance, up to 85°C
Ultra-wide angle, maximum horizontal viewing angle 130 degrees
|
Model |
SF-FN321G-ICR-G7 |
Camera |
Type |
In-vehicle Rear view camera |
Image sensor |
1/2.9" 2MP progressive scan CMOS |
|
Minimum illumination |
0.01Lux @(F1.2,AGC ON),0Lux (IR light on) |
|
Electronic Shutter |
Auto / Manual, 1/25~1/100000 |
|
Lens |
2.1mm |
|
IR |
2IR lights, IR distance up to 15 meters |
|
Video |
Video Compression |
H.264/h.265 |
Code rate |
128Kbps~8Mbps |
|
Maximum resolution |
Main:1920*1080(25/30fps), |
|
Image |
Wide Dynamic |
105DB |
Day/Night Mode |
Auto/B&W/color |
|
Noise Reduction |
Auto/Manual |
|
Exposure mode |
Auto/Manual |
|
Image flip |
Horizontal/vertical |
|
Network |
Network Protocol |
TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP, |
Docking Protocol |
ONVIF/CGI |
|
Cloud service |
P2P |
|
Interface |
Network port |
Six-core airline header ( 10M/100M Ethernet ) ( various connectors can be customized ) |
Audio input/output |
/ |
|
Other |
working temperature |
-30℃~85℃ |
Working Humidity |
10%~90% |
|
Waterproof |
IP69k |
|
Voltage |
DC12V±10%, less than 3W |
