1/2.9’ 2MP CMOS
Resolution: 2MP:1980*1080
Default output: AHD1080P
Low illumination up to 0.1lux
Full color, IP69K waterproof
|
|
model |
SF-FHD320W-G3 |
|
Main |
sensor |
GC2053,1/2.9’ cmos |
|
Resolution |
1920*1080, |
|
|
Video format |
PAL/NTSC |
|
|
Illuminance |
0.1Lux@F1.2 |
|
|
dynamic range |
≥70dB |
|
|
Synchronous Mode |
Internal synchronization |
|
|
Video out |
AHD（CVI,TVI,CVBS(Optional) |
|
|
Audio |
NA |
|
|
SNR |
≧ 50dB |
|
|
Lens |
2.8MM lens |
|
|
Day&Night |
Auto（ICR）/Color/Black White |
|
|
Shutter |
Auto |
|
|
White Balance |
Auto |
|
|
Gamma Correction |
0.45 |
|
|
water proof |
IP69K |
|
|
Video |
Connectors |
4pin Aviation connector |
|
|
Cable length |
0.5m |
|
Other |
power supply |
DC12V± 10% |
|
Current |
100mA |
|
|
Case |
Metal |
|
|
tooling hole diameter |
Ø28mm-Ø29mm |
|
|
Work Temp. |
-40°C ~ 70°C |
|
|
Storage temp. |
-40°C ~ 75°C |
