Model |
SF-900JM-MX |
|
Camera |
Image Device |
1/2.9" Sony Low Illumination CMOS |
Horizontal Resolution |
2.0M/1080P |
|
Effective Pixels |
1920(H)×1080(V) |
|
Mini. Illumination |
Color: 0.1Lux\ B/W: 0.01Lux / IR ON:0 Lux |
|
S/N |
≥50db |
|
Optical Zoom |
18X , 5.35mm~96.3mm |
|
IRIS |
F1.6~F2.4 |
|
White Balance |
Auto/manual/indoor/outdoor |
|
BLC |
Support |
|
Electronic Shutter |
1/2 - 1/20,000s |
|
WDR |
D_WDR |
|
Noise Reduction |
2D_DNR |
|
Day & Night mode |
IR-CUT |
|
Max. IR LEDs Length |
4PCS Laser Led,11pcs Array 42Mil Led , up to 200 meters , Smart IR |
|
Auto Control IR LED |
PWM |
|
IR illumination on |
1-15 grades selectable |
|
Support ambient light detection |
1-50 grades selectable |
|
Video Output |
HYBRID AHD/TVI/CVI/CVBS |
|
PTZ |
Horizontal |
360°endless rotate , Speed 0.02°/s-45°/s |
Tilt |
0.02°/s-30°/s |
|
Auto Flip |
Horizontal 180°, Vertical 93° |
|
A-B Scan |
User programmable |
|
A-B Scan Speed |
1-9 levels setting available |
|
Dwell Preset |
1-60s interval available |
|
Preset Points |
220 |
|
Go to Preset Speed |
01-64 levels available |
|
PWR On Action |
Memory/Tour 1/360° scan/A-B scan/Preset 1-8/None |
|
Baud Rate |
1200/2400/4800/9600bps ( Default is 9600bps ) |
|
Park Time |
01-60mins available |
|
Guard Tours |
3 groups |
|
Guard Points |
Max.16 points, dwell time user selectable |
|
General |
Operating temperature |
Indoor: 0°~ +40° Outdoor: -40°~ +60° |
Operation menu |
English |
|
Pan and Tilt position Display |
Support |
|
Support ambient light detection |
IR illumination on 1-9 grades selectable |
|
Humidity |
≤95% Non Condensing |
|
Power |
DC12V /4A |
|
Consumption |
15W (MAX) |
|
Protection Grade |
Transient voltage 6000V |
