Model |
SF-C61-P-(N)C-I-108 |
|
Camera |
Image Device |
1/2.9" Sony Low Illumination CMOS |
Horizontal Resolution |
2.0M/1080P |
|
Effective Pixels |
1920(H)×1080(V) |
|
Mini. Illumination |
0.01Lux(F1.2,AGC ON),0 Lux with IR ON |
|
S/N |
≥41db |
|
Optical Zoom |
3X , 2.8mm-8mm |
|
Angle View |
106.6° - 51.8° |
|
White Balance |
Auto/manual |
|
Exposure Mode |
Auto/manual |
|
BLC |
Support |
|
Gain Control |
Support |
|
Electronic Shutter |
1/30s~1/10,000s |
|
WDR |
D_WDR |
|
Noise Reduction |
3D_DNR |
|
Focus Mode |
Auto/Manual |
|
Day & Night mode |
Support |
|
Edge Illumination compensation |
Support |
|
Max. IR LEDs Length |
3pcs Array Leds , 20M , Smart IR |
|
Video Output |
1CH HD_AHD output |
|
PTZ |
Pan |
Pan 355°endless rotate , Speed 0-25°/S |
Tilt |
0-90°, Speed 0-20°/S |
|
Preset |
16 |
|
Patrol |
1 Group |
|
Pattern |
1 Group |
|
AB Scan |
Support |
|
Park Action |
Support Can select preset/patrol/pattern/AB scan |
|
General |
Video Port |
BNC Port |
Power Port |
DC12V/1A |
|
Consumption |
10W (MAX) |
|
Working Tem /Humidity |
-20°-+60° 10%~90% |
|
Protection Grade |
TVC3000W Lighting protection ,surge protection and voltage transient protection |
