◆ 1/4‘CMOS Sensor
HD Resolution: 1MP:1280*720
AHD 720P output as default
0.01 Low illumination
BMW cable，DC12V power supply
|
|
Model No. |
SF-CA63-TD7101-49G |
|
Main features |
Sensor |
SC101,1/4’ |
|
Resolution |
1280*720, |
|
|
System |
PAL/NTSC |
|
|
Min. Illumination |
0.1Lux@F1.2, 0Lux (IR ON) |
|
|
SNR |
≥70dB |
|
|
Sync. System |
Internal Synchronization |
|
|
Video Output |
AHD |
|
|
Audio |
Optional if need |
|
|
S/N Ratio |
≧ 48dB |
|
|
Lens |
2.1MM lens |
|
|
FOV |
130° |
|
|
Day&Night |
Auto（ICR）/Color/White&Black |
|
|
Shutter |
Auto |
|
|
White Balance |
Automatic tracking |
|
|
Gamma Correction |
0.45 |
|
|
IR LED |
5pcs IR LED, IR distance:3M |
|
|
Video |
Video Output |
3pin BMW connector |
|
|
Cable length |
0.5m |
|
Application |
Power Supply |
DC12V± 10% |
|
Power Consumption |
100mA(IR ON) |
|
|
Case materials |
Plastic case |
|
|
Working Temp. |
-40°C ~ 70°C |
|
|
Storage Temp. |
-40°C ~ 75°C |
