Model No.

SF-FHD621E-ICR-G3

Main features

Front

Back

Sensor

GC2053,1/2.9’CMOS

Resolution

1920*1080

System

PAL/NTSC

Min. Illumination

0.1Lux

0.1Lux@F1.2, 0Lux (IR ON)

DWDR

≥70dB

Sync. System

Internal Synchronization

Video Output

AHD

Audio

support

S/N Ratio

≧ 48dB

Lens

2.8MM lens

FOV

110°

Day&Night

Auto（ICR）/Color/White&Black

Shutter

Auto

White Balance

Automatic tracking

Gamma Correction

0.45

IR LED

No

5pcs IR LED, IR distance:3M

Video

Video Output

3pin BMW connector

Cable length

0.5m

Application

Power Supply

DC12V± 10%

Power Consumption

300mA(IR ON)

Case materials

Plastic case

Working Temp.

-40°C ~ 70°C

Storage Temp.

-40°C ~ 75°C
