Model

SF-AHD357IZ-4-ICR-M3

Camera

Image Device

1/2.7" 5.0MP CMOS

Horizontal Resolution

5.0M

Effective Pixels

2592H x 1944V

Electronic Shutter

1/25s~1/50,000s

Image System

PAL/ NTSC

Synchronization

Internal

Mini. Illumination

0.01Lux(F1.2,AGC ON),0 Lux with IR ON

Max. IR LEDs Length

4pcs Array Leds , 40M , Smart IR

Day/Night

IR Cut Filter Auto Switch

Lens Type

M14 HD Vari Focus 2.8-12mm

Video Output

1CH HD_AHD/960H output

OSD

OSD Menu

UTC , External OSD Joystick (Optional )

Noise Reduction

3D_DNR

BLC

Auto

WDR

D_WDR

General

Transmission Distance

Over 500m via 75-3 coaxial cable

Waterproof

IP66

Working Temperature

-10℃~50℃

Working Humidity

10%~90%

Power Consumption

450 mA

Power Supply

DC12V±10%
