* Adopt 1/2.9‘‘ 2.0 Megapixels CMOS Sensor
* 1920×1080 High Definition Image
* Control OSD Menu via Coaxial Cable
* Over 500 Meters Coaxial Cable Transmission
* Hybrid AHD/TVI/CVI/CVBS Signal output
* Support 3DNR
* Support Smart IR Function
Model |
SF-FHD322L-C-DS4 |
|
Camera |
Image Device |
1/2.9" 2.0MP STARVIS CMOS |
Horizontal Resolution |
2.0M/1080P |
|
Effective Pixels |
1920(H)×1080(V) |
|
Electronic Shutter |
1/25s~1/50,000s |
|
Image System |
PAL/ NTSC |
|
Synchronization |
Internal |
|
Mini. Illumination |
0.008LUX@F1.2 |
|
Max. IR LEDs Length |
/ |
|
Day/Night |
24 Hours Color |
|
Lens Type |
Starlight F1.4 3.6MM |
|
Video Output |
1CH HD_AHD/TVI/CVI/960H output |
|
OSD |
OSD Menu |
UTC , External OSD Joystick (Optional ) |
Noise Reduction |
3D_DNR |
|
BLC |
Auto |
|
WDR |
D_WDR |
|
General |
Transmission Distance |
Over 500m via 75-3 coaxial cable |
Waterproof |
IP66 |
|
Working Temperature |
-10℃~50℃ |
|
Working Humidity |
10%~90% |
|
Power Consumption |
210 mA |
|
Power Supply |
DC12V±10% |
