Model |
SF-SN623SIR-ICR-L1 |
|
|
Camera |
Sensor |
1/2.8" 2.0MP Progressive Scan CMOS |
|
Min. Illumination |
0.001Lux @(F1.2,AGC ON),0Lux with IR ON |
|
|
Shutter |
Auto /Manual, 1/25~1/100000 |
|
|
Lens Type |
2.8-12MM (3.6MM Optional) |
|
|
IR LEDS |
22PCS LEDs, IR distance 20 meters |
|
|
Video Compression |
H.264/H.265 |
|
|
Bit Rate |
128Kbps~8Mbps |
|
|
Max .Resolution |
Main Stream: 1920×1080(25/30fps), Sub Stream: 720×576(25/30fps) |
|
|
WDR |
SUPER WDR |
|
|
Day&Night |
Auto/Black&White/Color |
|
|
Noise Reduction |
Auto/manual |
|
|
Exposure Mode |
Auto/manual |
|
|
Flip |
Horizontal/Vertical |
|
|
Audio Compression |
G.711 |
|
|
Network |
Protocols |
TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP, RTCP,PPPOE,NTP,SMTP |
|
Interface Protocols |
ONVIF /Private CGI |
|
|
Cloud |
P2P |
|
|
Network |
RJ45 ( 10M/100M Ethernet) |
|
|
General |
Audio input/output |
Optional |
|
Alarm input/output |
Optional |
|
|
Micro SD Slot |
/ |
|
|
Waterproof |
Plastic Indoor |
|
|
Working Temperature |
-10℃~50℃ |
|
|
Working Humidity |
10%~90% |
|
|
Power Consumption |
290 mA |
|
|
Power Supply |
DC12V±10% Buil-in POE Optional |
|
